Unity Elite Pro 40 FB4 (IP65)

$13,451.00

  • Output Power: 44 Watts total (RGB)
  • Red Diode: 8.8W at 637nm
  • Green Diode: 13.2W at 520nm
  • Blue Diode: 22W at 455nm
  • Beam Size: 7.5 mm (± 0.5 mm)
  • Beam Divergence: <1.0 mrad full angle
  • Scanning Speed: 30,000 points per second at 8°
  • Scan Angle: 45° maximum
  • Control Options: ILDA, Ethernet, DMX, ArtNet, sACN
  • Software Included: QuickShow
  • IP Rating: IP65 (dust and water-resistant)
  • Power Requirements: 100-230V, 50-60Hz
  • Dimensions: 485 x 506 x 263 mm
  • Weight: 33 kg
Add to cart
Product code: N/A
Social share:

Item description

The Elite 40 PRO FB4 IP65 is a high-powered laser projector designed for large-scale events and outdoor applications. With an impressive 44W output, this robust projector delivers powerful, bright laser beams suitable for venues with up to 50,000 attendees. Its IP65-rated housing ensures protection against dust, rain, and harsh conditions, making it a top choice for both indoor and outdoor installations.

Superior Performance and Color Accuracy

Exceptional Brightness and Beam Quality
The Elite 40 PRO uses RGB diodes to create vivid, bright colors and sharp beams. Thanks to its optical correction technology, the projector maintains a consistent beam profile, even over long distances. This ensures that every laser display, whether it’s a beam show or graphics projection, is crisp and clear. The system’s advanced diodes offer enhanced visibility, making it perfect for outdoor settings with high ambient light.

Flexible Control Options
The FB4 control system provides flexible operation modes, allowing users to control the projector through Ethernet, DMX, ArtNet, or sACN. This flexibility makes the Elite 40 PRO FB4 IP65 easy to integrate into various lighting setups. The included QuickShow software enables easy design and control of custom laser shows. Users can run the system from a PC or automate it for hands-off operation, ensuring smooth performances at any event.

Built for Large Venues and Outdoor Events

Advanced Scanning and Precision Control
With its high-speed XY scanning system, the Elite 40 PRO handles complex beam shows and intricate graphics effortlessly. The projector offers a scanning speed of 30,000 points per second at 8°, allowing for smooth, detailed laser animations. The system also features a wide 45° scan angle, ensuring broad coverage for large venues and stages.

Durable and Weather-Resistant
The IP65-rated housing protects the Elite 40 PRO from dust, rain, and extreme weather conditions, making it ideal for permanent outdoor installations and large-scale events. This level of protection ensures reliable operation in tough environments, allowing for seamless laser shows without worrying about the elements.

Key Specifications

  • Output Power: 44 Watts total (RGB)
  • Red Diode: 8.8W at 637nm
  • Green Diode: 13.2W at 520nm
  • Blue Diode: 22W at 455nm
  • Beam Size: 7.5 mm (± 0.5 mm)
  • Beam Divergence: <1.0 mrad full angle
  • Scanning Speed: 30,000 points per second at 8°
  • Scan Angle: 45° maximum
  • Control Options: ILDA, Ethernet, DMX, ArtNet, sACN
  • Software Included: QuickShow
  • IP Rating: IP65 (dust and water-resistant)
  • Power Requirements: 100-230V, 50-60Hz
  • Dimensions: 485 x 506 x 263 mm
  • Weight: 33 kg

Safety and Easy Setup

Built-In Safety Features
The Elite 40 PRO FB4 IP65 includes a range of safety features such as emission delay, keyed interlock, scan-fail protection, and a mechanical shutter. These safety measures ensure the laser operates securely, even in high-traffic environments like concerts or large festivals. The system also has external adjustments for beam size, position, and rotation, offering complete control over the laser’s output.

Quick Installation and Setup
With its integrated network switch, multiple lasers can be synchronized and controlled from a single location, simplifying setups for large-scale shows. The Elite 40 PRO is designed for fast installation, making it ideal for event professionals who need to set up and break down equipment quickly.

Conclusion

The Elite 40 PRO FB4 IP65 is the ideal laser projector for large venues, festivals, and outdoor shows. Its 44W output, flexible control options, and rugged, weather-resistant design make it perfect for demanding environments. Whether you’re organizing a large-scale concert or looking for a reliable projector for permanent installation, the Elite 40 PRO FB4 delivers unmatched performance and safety.
